Configuration	Console
Printing Process	4-Drum Method
Control Panel	10.1" Smart Operation Panel
Color/Black & White	Color
Output Speed Copy/Print	35 ppm B&W & FC (LTR)
First Page Out Time	4.0 seconds B&W 6.6 seconds Color
Warm-Up Time	25 seconds
Resolution	600 dpi
System Memory	4 GB RAM Mainframe + 4 GB RAM Panel/256 GB SSD
Maximum Copy Quantity	Up to 999 copies
Duplexing	Automatic (Standard)
Document Feeder Type	Single Pass Document Feeder (SPDF)
Single Pass Document Feeder (SPDF)	Original Capacity: 220 sheets Original Size: 2" x 3.5" - 11.7" x 17" (A6-A3, B8-B4) Paper Weight: Simplex/Duplex: 38 – 220 g/m2 (A6 or larger); 64 – 220g/m2 (smaller than A6)
Zoom Range	25% - 400% in 1% increments
Supported Paper Sizes	1st Paper Tray: 8.5" x 11" (A4) 2nd Paper Tray: 5.5" x 8" - 12" x 18" (A6-A3, B4-B6), Envelopes Bypass: Up to 12" x 18", Envelopes Custom Sizes: Width: 3.5" - 12.6" (90 - 320 mm), Length: 5.8" - 49.6" (148 - 1260 mm)
Supported Paper Weights	Standard Trays: 16 - 80 lb./166 lb. Index (60 - 300 g/m2) Bypass Tray: 14 - 80 lb./166 lb. Index (52 - 300 g/m2) Duplex Unit: 14 - 45lb./142 lb. Index (52 - 169 g/m2)
Supported Paper Types	Plain, Recycled, Special, Colored, Letterhead, Cardstock, Pre-printed, Coated, Envelope, Label, Gloss
Standard Paper Capacity	1,200 sheets (2 x 550 sheets + 100-Sheet Bypass Tray)
Maximum Paper Capacity	4,700 sheets (w/Tandem LCT + Side LCT)
Standard Output Capacity	500 sheets 8.5" x 11" (A4) or smaller; 250 sheets (B4) or larger
Maximum Output Capacity	1,625 sheets
Maximum Monthly Volume	20000
Power Source	120V - 127V, 60Hz
Typical Electricity Consumption (TEC)	0.35 kWh/week TEC value is measured based on the ENERGY STAR Ver.3.0 test method.
Power Consumption	Less than 1,584 W; Sleep Mode: 0.3W
EPEAT Status	Gold
Dimensions W x D x H	23.0" x 27.0" x 37.9" (587 mm x 685 mm x 963 mm)
Weight	218.9 lbs/99.3 kg
